Description
| Model | CK5116 |
| Max. turning diameter (mm) | 1600 |
| Max. height of workpiece (mm) | 1200 |
| Max. weight of workpiece (t) | 5 |
| Table diameter (mm) | 1400 |
| Speed range of table (r/min) | 5-160 |
| Speed step of table | 16 |
| Travel of railhead horizontal (mm) | 915 |
| Travel of railhead vertical (mm) | 800 |
| Travel of slidehead horizontal (mm) | 630 |
| Travel of slidehead vertical (mm) | 980 |
| Travel of cross rail (mm) | 850 |
| Max. tool holder size | 30×40 |
| Swivel of rail head | ±30° |
| Range of feeds rates (mm/min) | 0.8-86 12 steps |
| Rapid traverse speed of vertical or side tool head | 1800 |
| System | FANUC |
| Power of main motor (kw) | 30 |
| Overall dimension(mm) | 2830×22670×3010 |
| Machine weight(t) | 12.5 |
